IronCraft 2510 Series: 10′ Flex-Wing Rotary Cutter 540 RPM 4 LAMINATED TIRES

IronCraft 2510 Series: 10′ Flex-Wing Rotary Cutter 540 RPM 4 LAMINATED TIRES

The IronCraft 2510 Flex-Wing Cutter is engineered to deliver high-performance results with surprisingly low horsepower requirements. Ideal for landowners managing tough terrain, this 123″ working width cutter combines a high-speed gearbox with heavy-duty construction.

Design efficiency is at the forefront of the 2510 series, featuring a flat-top deck for easy cleaning and a narrow 96.5″ transport width for effortless mobility between jobsites. Whether you are clearing brush up to 2″ in diameter or maintaining expansive pastures, this flex-wing cutter provides the reliability you expect from IronCraft.

Core Performance Features

• Low HP Requirement: Operates efficiently with only 25–60 PTO horsepower.
• Flexible Maneuverability: Wing flex ranges from 20° down to 85° up for uneven landscapes.
• Superior Cutting Protection: Equipped with round stump jumpers and a 175 HP-rated main gearbox.
• Low Maintenance: Features an 11-gauge flat top deck and replaceable skid shoes.

Detailed Technical Specifications

• Working Width: 123″ (10′ Dual Spindle Flex-Wing)
• Cutting Capacity: Clears brush up to 2″ diameter
• Cutting Height: Adjustable from 1-3/4″ to 11-1/2″
• Transport Width: 96.5″ for easy gate and road access
• Deck Height: 11″ with 7-gauge side bands

Drivetrain & Hardware

• Gearbox Rating: 175 HP (Center) / 75 HP (Outboard)
• PTO Drive Shaft: ASAE CAT 5 (Main) / ASAE CAT 4 (Wing)
• Driveline Protection: Slip Clutch standard
• Blade System: 1/2″ x 3″ Uplift blades with 5-1/4″ overlap
• Tire Type: Four 20″ Laminated tires for maximum stability

Standard Safety & Warranty

• Gearbox Warranty: 5-Year Limited Warranty
• Guarding: Single row chains included as standard
• Hitch: Swivel pivot self-leveling hitch for smooth towing
• Safety: Standard safety tow chain included
