IronCraft T624: 24′ Six-Basket Hay Tedder with Hydraulic Leveling

IronCraft T624: 24′ Six-Basket Hay Tedder with Hydraulic Leveling

The IronCraft T624 is a professional-grade 24-foot Six-Basket Hay Tedder, engineered for high-output operations using tractors between 50 and 60 PTO horsepower. This massive 24′ implement is designed to cover vast acreage in record time, ensuring your forage is fluffed, spread, and dried uniformly to lock in peak nutritional value.

Equipped with hydraulic wing folding and hydraulic working angle adjustment, the T624 allows for total control from the tractor cab. Its standout feature is the walking tandem wheel system, which provides unparalleled stability and ground following on uneven terrain, preventing tine damage and soil contamination.

High-Capacity Precision & Forage Features

• Expansive 24′ Working Width: Maximize your field efficiency by covering more ground in every pass, perfect for beating tight weather windows.
• Six-Rotor Distribution System: Six independent rotors work in sync to lift and distribute heavy windrows, ensuring even air circulation and rapid dry-down.
• Walking Tandem Axles: Features 8 flotation tires (16 x 6.5-8) in a walking tandem configuration to glide over ruts and ridges for the smoothest possible operation.
• Hydraulic Leveling: Adjust the pitch of the rotors on the fly to match crop conditions without leaving the operator’s seat.

Technical Specifications (Model T624)

• Working Width: 24 Feet
• Horsepower Requirement: 50 – 60 PTO HP
• Rotor Configuration: 6 Baskets with High-Strength Tines
• Transport Dimensions: 9.8′ Transport Width x 12.1′ Transport Height
• Operating Weight: 1,740 lbs for industrial durability
• Safety: Road Signaling Kit included as standard equipment
• Hydraulic Requirements: 2 Rear Remotes Required

Industrial Build Quality & Design

• Heavy-Duty Pull-Type Hitch: Designed for stable tracking behind utility tractors at high field speeds.
• Articulated Frame Sections: Allows the 24-foot frame to flex and follow complex field contours effortlessly.
• Hydraulic Wing Fold: Folds to a compact 9.8′ width for safe travel through gates and on public roads.
• Premium Road Signaling: Standard lighting kit ensures visibility during transport between far-flung fields.

Primary Commercial Haying Applications

• Large-Scale Forage Operations: The 24-foot reach is a game-changer for commercial alfalfa, grass, and cereal grain hay producers.
• High-Speed Curing: Engineered for contractors who need to process massive volumes of hay per hour while maintaining perfect forage quality.
• Variable Terrain Harvesting: The walking tandem wheels make this the best choice for rough, terraced, or undulating hay fields.
• Professional Crop Management: Achieve perfectly consistent moisture levels across the entire field for safer, more efficient baling.
