IronCraft VH Series: 90″ Extreme-Duty Gear-Drive Rotary Tiller

IronCraft VH Series: 90″ Extreme-Duty Gear-Drive Rotary Tiller

The IronCraft VH-90 is an industrial-strength 90-inch Extreme-Duty Rotary Tiller engineered for high-horsepower tractors ranging from 75 to 125 PTO HP. This powerhouse is built to dominate the most punishing soil conditions, from heavy clay and compacted earth to virgin ground clearing for large-scale agricultural and commercial projects.

As our most rugged tillage implement, the VH-90 features an overbuilt gear-drive system and is Category 2 and 3 hitch compatible. With a massive 1,557 lb frame, this tiller provides the immense down-pressure and torque required to achieve deep soil inversion where standard tillers fail.

Industrial Performance & Extreme-Duty Features

• Premium Gear-Driven Transmission: Designed for maximum power transfer, the heavy-duty gear drive handles the high torque of 125 HP tractors without the maintenance concerns of chain systems.
• Deep-Earth Penetration: Achieve a maximum working depth of 9″, providing superior aeration and the deep seedbed preparation required for high-yield root crops.
• High-Mass Rotor System: Features a 3-1/2″ diameter rotor and 54 total tines (6 per flange) to pulverize clods and incorporate heavy residue in a single pass.
• 90-Inch Wide Coverage: The 7.5-foot working width ensures maximum productivity on large acreage, easily covering the tire tracks of large utility and row-crop tractors.

Technical Specifications (Model VH-90)

• Working Width: 90″ (7.5 Feet)
• Horsepower Requirement: 75 – 125 PTO HP
• Operating Weight: 1,557 lbs for ultimate ground engagement
• Hitch Compatibility: Dual Category 2 & 3 (Cat 2 & 3)
• Rotation: Forward Rotation at 540 RPM
• Overall Width: 95″ for full coverage

Rugged Build Quality & Engineering

• Heavy-Wall Frame: Reinforced structural steel frame designed to absorb the shocks and vibrations of industrial-scale tilling.
• High-Carbon Steel Tines: Specialized tines designed for long wear life in abrasive and stony soil conditions.
• Substantial Rotor Swing: A 17″ swing diameter ensures efficient material rolling and thorough soil mixing.

Primary Industrial & Agricultural Applications

• Large-Scale Crop Production: Prepare hundreds of acres for planting with industrial-grade efficiency.
• Land Reclamation & Clearing: The weight and torque make it ideal for breaking up virgin soil or reclaimed pasture.
• Commercial Site Preparation: Perfect for leveling large building sites, parks, or athletic fields where deep soil aeration is required.
• Vegetation Incorporation: Effortlessly till in thick cover crops, orchard trimmings, or heavy organic mulch to improve soil structure.
