IronCraft BRF-160: 63″ Heavy-Duty Offset Flail Mower

IronCraft BRF-160: 63″ Heavy-Duty Offset Flail Mower

The IronCraft BRF-160 is a high-performance offset flail mower designed for tractors with 70-100 PTO horsepower. Engineered for extreme versatility, this robust machine excels at shredding thick grass, stubborn weeds, and brushwood up to 2” in diameter, even on the most challenging uneven terrain.

Part of the innovative BRF line, this model is the premier choice for maintaining ditch banks, pond edges, and orchards. Its hydraulic offset and tilt capabilities allow you to reach areas that standard mowers cannot, making it an essential tool for precision mowing along fence lines and steep embankments.

Key Performance & Maneuverability Features

• Dynamic Tilt Range: Highly flexible cutting head tilts 90 degrees upward and 65 degrees downward for superior sloped mowing.
• Hydraulic Offset Capability: Conveniently offsets to the right to keep the tractor on stable ground while reaching over edges.
• Industrial Mulching Power: Equipped with 14 heavy-duty hammers (4.9″ x 1.7″) specifically designed for aggressive material reduction.
• Enhanced Durability: Features a Series 6 PTO drive shaft and a 4-belt side transmission for maximum power transfer and longevity.

Technical Specifications (Model BRF-160)

• Working Width: 63″ cutting path.
• HP Requirement: 70–100 PTO HP.
• Hydraulic Requirements: Requires 2 sets of rear tractor remotes.
• Rotor & Roller: Features a massive 6.3″ diameter rotor and 7.6″ diameter rear roller for stability.
• Operating Weight: 1,433 lbs for increased down-pressure and structural integrity.

Industrial Build & Hardware

• Hammer Configuration: 14 High-mass hammers (available with hammers only).
• Drive System: 4-belt side transmission to protect against shock loads.
• Hitch Compatibility: Designed for tractors within the 20-100 HP range.
• Specialized Utility: Ideal for orchards, vineyards, and municipal roadside maintenance.

Ideal Applications

• Ditch & Bank Maintenance: The 65-degree downward tilt makes it a leading choice for steep bank management.
• Vertical Clearing: Use the 90-degree upward tilt for trimming tall hedge rows or clearing vertical obstacles.
• Precision Edging: The hydraulic offset allows for perfect tracking along fence lines and pond perimeters.
